Evaluation boards

Kickstart your development with our Evaluation Boards. Designed to offer you a hands-on experience, they are perfect for testing, development, and prototyping your next big idea.


Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
W5500-EVB-Pico2
W5500-EVB-Pico2
RP2350A
W5500
UART x 2, I2C x 2, SPI x 2
RJ45
80 x 21
W5100S-EVB-Pico2
W5100S-EVB-Pico2
RP2350A
W5100S
UART x 2, I2C x 2, SPI x 2
RJ45
80 x 21

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
W6100-EVB-Pico2
W6100-EVB-Pico2
RP2350A
W6100
UART x 2, I2C x 2, SPI x 2
RJ45
80 x 21
W55RP20-EVB-Pico
W55RP20-EVB-Pico
W55RP20
RJ45

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
W5500-EVB-Pico
W5500-EVB-Pico
RP2040
W5500
UART x 2, I2C x 2, SPI x 2
RJ45
75 x 21
W5100S-EVB-Pico
W5100S-EVB-Pico
RP2040
W5100S
UART x 2, I2C x 2, SPI x 2
RJ45
75 x 21

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
W6100-EVB-Pico
W6100-EVB-Pico
RP2040
W6100
UART x 2, I2C x 2, SPI x 2
RJ45
75 x 21
WizFi360-EVB-Pico
WizFi360-EVB-Pico
RP2040
-
UART x 2, I2C x 2, SPI x 2

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
Surf5
Surf5
W7500
W7500
RJ45
75 x 15.9
WIZwiki-W7500
WIZwiki-W7500
W7500
W7500
83.71 x 55.44

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
WIZwiki-W7500P
WIZwiki-W7500P
W7500P
W7500P
83.71 x 55.44
W5500-EVB
W5500-EVB
NXP LPC11E36
W5500
RJ45
93 x 53 x 17.3

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
W6100-EVB
W6100-EVB
STM32F103
W6100
RJ45
90 x 80 x 15
W5100S-EVB
W5100S-EVB
STM32F103
W5100S
SPI, I2C, UART
RJ45
90 x 80 x 15

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
W5100E01-AVR
W5100E01-AVR
ATMEL Atmega 128
W5100
2 x RS232
RJ45
WIZ750SR-EVB(RS232/TTL)
WIZ750SR-EVB(RS232/TTL)
-
-
RS-232C Connector, D-SUB9-MALE
RJ45
83 x 65 x 18

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
WIZ750SR-EVB(RS422/RS485)
WIZ750SR-EVB(RS422/RS485)
-
-
RS-422/485 Connector, ECH381R.
RJ45
73 x 65 x 18
WIZ500SR-RP-EVB
WIZ500SR-RP-EVB
-
-
-
RJ45
50 x 30 x 14.95

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
WIZ505SR-RP-EVB
WIZ505SR-RP-EVB
-
-
RS232C x 1
-
WIZ550SR-EVB
WIZ550SR-EVB
-
-
UART x 1
RJ45

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
WIZ750SR-100-EVB
WIZ750SR-100-EVB
-
-
RS232
RJ45
105 x 70 x 19
WIZ550S2E-485-EVB
WIZ550S2E-485-EVB
61 x 45

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
WIZ550S2E-232-EVB
WIZ550S2E-232-EVB
61 x 45
WizSE-EVB
WizSE-EVB
TTL x 1
RJ45

Core
Ethernet IC
Serial Interface
Ethernet Interface
Size
WizFi360-EVB-Shield
WizFi360-EVB-Shield
-
-
WizFi360-EVB-Mini
WizFi360-EVB-Mini
-
-
